Evaluation of some Non-Edible Vegetable Oils as Lubricants for Conventional and Non-Conventional Metal Forming Processes
No Thumbnail Available
Date
2019
Authors
Idegwu, CU
Olaleye, SA
Agboola, JB
Ajiboye, JS
Journal Title
Journal ISSN
Volume Title
Publisher
ESAFORM
Abstract
The current study focuses on evaluation of the suitability of some non-edible vegetable-based oils as lubricants
for conventional metal forming operations in general and non-conventional processes such as severe plastic deformation
in particular. Four non-edible oils were chemically extracted using a Soxhlet extractor and hexane solvent from mango
seeds, water-melon seeds, African cherry seeds and avocado peer seeds. Comparison was made between performance of
these environmentally benign oils and a mineral based SAE 40 Oleum super monograde oil in the equal channel angular
extrusion (ECAE) of a cylindrical AA 6063 aluminum rod through a channel angle φ of 90o and outer angle ψ of 20o at
different extrusion speed. The results show that mango oil has the best load reduction for all extrusion speeds tested, better than SAE 40, followed by avocado oil, then watermelon oil with cherry oil given the least performance. It was found, regardless of any of these oils tested, that as extrusion speed increases, there is a reduction in the load and hardness of the material tested. Comparing the unECAEed specimens with the ECAEed specimens, hardness decreases in all the ECAEed specimens tested. Further, from the hardness measurement, it was found that specimens ECAEed with vegetable-based oils probably produced better grain homogeneity than specimens ECAEed with SAE40, which perhaps account for their slightly higher hardness values. Also, although the viscosity of the SAE 40 is better than mango and avocado oils, these vegetable based oils performed excellently well when used as lubricants during equal channel angular extrusion of AA 6063 aluminum and show promising potential as alternative to mineral oil, SAE 40.
Description
Keywords
lubricants, ECAEed, unECAEed, aluminum, SPD, environmentally benign
Citation
Idegwu et al., AIP Conference Proceedings 2113, 030004 (2019)
